Sony DCR-TRV240 User Manual

— 10 —
DCR-TRV240/TRV340
E
E
E
E
Block
Function
61
61
62
62
Detailed
Code
00
10
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Handshake correction function does not
work well. (With pitch angular velocity
sensor output stopped.)
Handshake correction function does not
work well. (With yaw angular velocity
sensor output stopped.)
Self-diagnosis Code
Repaired by:
Correction
Inspect the lens block focus reset sensor (Pin qd of CN1551 of
VC-276 board) when focusing is performed when the focus ring is
rotated in the focus manual mode and the focus motor drive circuit
(IC1553 of VC-276 board) when the focusing is not performed.
Inspect the lens block zoom reset sensor (Pin qs of CN1551 of
VC-276 board) when zooming is performed when the zoom switch
is operated and the zoom motor drive circuit (IC1553 of VC-276
board) when zooming is not performed.
Inspect pitch angular velocity sensor (SE301 of SE-032 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE302 of SE-032 board)
peripheral circuits.

Sony DCR-TRV240 Specifications

General

Digital zoom	700 x
Optical zoom	25 x
Image stabilizer	Yes
Focal length range	2.4 - 60 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/6 \
Display diagonal	2.5 \
Minimum illumination	4 lx

Weight and Dimensions

Depth	101 mm
Width	85 mm
Height	206 mm
