HCD-LV100AV
3939
• Waveforms
– VIDEO Board –
1 IC501 wf (LRCK)
2 IC501 qd (BCLK)
3 IC502 qd (XOUT)
4 IC502 qg (XIN)
5 IC502 rg (BUS)
6 IC505 3 (CD-BCK)
7 IC505 5 (CD-LRCK)
8 IC505 yl (Y-OUT)
9 IC505 ug (C-OUT)
q; IC505 ih (DA-XCLK)
qa IC505 od
(PGIO2/VSYNK/CSYNK)
qs IC505 (VCK-IN)
106
qd IC505 (DA-LRCK),
108
IC509 ql (LRCK)
qf IC505 (DA-BCK),
111
IC509 qj (BCK)
qg Q301 (Base)
qh Q303, Q304 (Base)
qj Q308 (Base)
qk IC509 4 (MCKO)
ql IC509 w; (384FSO)
w; IC509 wa (768FSO)
wa IC509 wf (XT2)
ws IC401 7
wd IC401 5
wf IC401 3
wg IC401 1
wh J301 3 (COUT)
wj J301 4 (YOUT)
5 Vp-p
22.8 µ s
4.4 Vp-p
472 ns
4.1 Vp-p
10 MHz
3.3 Vp-p
10 MHz
4.8 Vp-p
16.7 ms
4.8 Vp-p
472 ns
4.8 Vp-p
22.8 µ s
1.7 Vp-p
H
H
0.5 Vp-p
5.2 Vp-p
60 ns
3.1 Vp-p
16.7 ms
4.3 Vp-p
8.7 ms
6 Vp-p
22.6 µ s
4.8 Vp-p
472 ns
1.8 Vp-p
H
H
1 Vp-p
0.9 Vp-p
H
4.9 Vp-p
37 ns
5.1 Vp-p
59 ns
4.8 Vp-p
30 ns
1 Vp-p
27 MHz
1.8 Vp-p
H
1 Vp-p
H
1 Vp-p
H
2 Vp-p
H
H
1 Vp-p
1.7 Vp-p
H
– BD Board – – MAIN Board –
1 IC101 wh (MDP)
2 IC101 el (FE)
(CD Play mode)
3 IC101 ra (TE)
(CD Play mode)
4 IC101 rd (RFDC)
(CD Play mode)
5 IC101 t; (RFAC)
(CD Play mode)
6 IC101 yg (LRCK)
7 IC101 yj (BCLK)
8 IC101 ua (XTAI)
9 IC103 qh (RFO)
(CD Play mode)
1.3 Vp-p
1.3 Vp-p
1.3 Vp-p
0.5 mVp-p
0.2 mVp-p
5.2 Vp-p
22.7 µ s
5.2 Vp-p
474 ns
5.2 Vp-p
16.9344 MHz
2.6 Vp-p
7.5
µ s
1 IC501 q; (XC-IN)
2 IC501 qg (XIN)
1.5 Vp-p
32.768 kHz
2.1 Vp-p
16 MHz
1 IC601 us (XOUT)
4.5 Vp-p
12.5 kHz
– PANEL FL Board –
