Sony HXCU-100 Service Manual

3-4 (E)
HXCU-100
Selecting PGM Audio Signal
Select the PGM audio signal of the headset connected to the front INTERCOM connector to a desired
level with C07: PGM SEL of the CCU menu.
To select PGM1: PGM1 (factory setting)
To select PGM2: PGM 2
To select PGM1 and PGM2 mixed: PGM1+PGM2
Headset output selection
C07:PGM MIX (CCU menu)
INCOM + PGM OFF L-INCOM/R-PGM
MIC/PGM switch
ON
Intercom + PGM
Intercom
Left: Intercom
Right: PGM
OFF
PGM PGM
Adjusting PGM Audio Signal Mixing Volume
Adjust the PGM audio signal mixing volume of the headset connected to the front INTERCOM connector
to a desired level with C07:PGM1 LVL, PGM2 LVL of the CCU menu.
Selecting Intercom Line to Be Connected to the INTERCOM Connector
Select the intercom line to be connected to the front INTERCOM connector as follows with the INTER-
COM switch.
Producer line: PROD
Engineer line: ENG
Communication only between CCU and camera: PRIV
