Sony NEX-FS700 User Manual

70
Changing/checking the settings in your
camcorder
You can display information such as time
code, etc., on the image.
Press the DISPLAY button (B or
D).
The screen indicators turn on (displayed)
and off (not displayed) as you press the
button.
In the recording mode, the screen changes
in the order, detailed display t simple
display t no display with each press of the
button.
z Tips
• You can display the screen indicators during
playback on a TV. Select [ALL OUTPUT] of
[DISPLAY OUTPUT] (p. 98).
You can display information, including
date, time and camera data automatically
stored during recording on the screen
during playback.
Press the DATA CODE button A
during playback or pause.
The screen changes in the order, date and
time display t camera data display t no
display with each press of the button.
A White balance
appears during playback of the
movie recorded with [MANU WB
TEMP].
B Shutter speed
C Iris
D Gain/ISO sensitivity
E Exposure
appears during playback of the
movie recorded with the iris, gain, ISO
sensitivity or shutter speed
automatically adjusted. appears
during playback of the movie recorded
with the iris, gain, ISO sensitivity or
shutter speed manually adjusted.
F SteadyShot
Changing the screen display
Displaying recording data (Data
code)

Sony NEX-FS700 Specifications

General

HD type	-
Capture modes	FH, FXP, HQ, LP
Maximum frame rate	60 fps
Supported video modes	720p, 1080i, 1080p
Video formats supported	AVCHD, MPEG2, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	28 Mbit/s
Audio system	Dolby Digital 2.0
Built-in microphone	Yes
Audio formats supported	LPCM
Filter size	67 mm
Digital zoom	- x
Optical zoom	11.1 x
Image stabilizer	No
Focal length range	18 - 200 mm
Lens mount interface	Sony E
Maximum aperture number	6.3
Minimum aperture number	3.5
Focal length (35mm film equivalent)	27 - 300 mm
Sensor type	CMOS
Total megapixels	11.6 MP
Display diagonal	3.5 \
Display resolution	1920 x 480 pixels
Display resolution (numeric)	921600 pixels
Camcorder type	Handheld camcorder
Minimum illumination	1.2 lx
Camera shutter speed	1/60 - 1/2000 s
Battery life (max)	8.5 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Camcorder media type	Memory card
Compatible memory cards	MS PRO Duo Mark 2, MS Pro-HG, MS Pro-HG Duo HX, SD, SDHC, SDXC
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
HDMI version	1.4
Composite video out	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black

Weight and Dimensions

Depth	101.5 mm
Width	126.5 mm
Weight	1470 g
