Sony STR-DH590 Help Guide

Help Guide
MULTI CHANNEL AV RECEIVER
STR-DH590
Naming preset stations [Name In]
You can enter up to 8 characters as the name for a preset station.
Canceling naming preset stations
Press BACK.
Hint
This operation can also be performed using the display panel on the receiver by pressing AMP MENU.
Related Topic
List of settings that can be adjusted using the menu on the display panel
4-731-210-11(1) Copyright 2018 Sony Corporation
Select [Listen] - [FM] from the home menu.
The FM screen appears.
1
Select [Preset List].
2
Press
/ to select the preset number to which you want to assign a name, then press .
This will take you back to the FM preset screen.
3
Select [Name In].
4
Press
/ repeatedly to select a character, then press .
To move the input position forward or backward, press
/ .
5
Repeat step 5 to input characters one by one, then press
.
The name you entered is registered.
To change the names of other preset stations, repeat steps 1 to 6.
6
19

Sony STR-DH590 Specifications

General

Receiver type	Surround
Output impedance	6 - 16 Ω
Audio output channels	5.2 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
Digital audio optical in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Supported radio bands	FM
Preset stations quantity	30
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS 96/24, DTS-HD HR, DTS-HD Master Audio, Dolby Digital, Dolby Dual Mono
Consumer Electronics Control (CEC)	BRAVIA Sync
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	297 mm
Width	430 mm
Height	133 mm
Weight	7100 g
