Sony STR-DH590 Help Guide

Help Guide
MULTI CHANNEL AV RECEIVER
STR-DH590
Selecting the Auto Calibration type [Calibration Type]
You can select a calibration type after you have performed the Auto Calibration and saved the settings.
For details on Auto Calibration, refer to the supplied Operating Instructions.
Note
This function does not work in the following cases:
[Direct] is selected and an analog input is selected.
Headphones are connected.
The receiver may play signals at a lower sampling frequency than the actual sampling frequency of the input signals, depending
on the audio format.
4-731-210-11(1) Copyright 2018 Sony Corporation
Select [Sound Effect] - [Calibration Type] from the home menu.
1
Press / to select the setting you want.
Full Flat: Makes the measurement of frequency from each speaker flat.
Engineering: Sets to “the Sony listening room standard” frequency characteristics.
Front Ref.: Adjusts the characteristics of all of the speakers to match the characteristics of the front speaker.
Off
2
27

Sony STR-DH590 Specifications

General

Receiver type	Surround
Output impedance	6 - 16 Ω
Audio output channels	5.2 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
Digital audio optical in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Supported radio bands	FM
Preset stations quantity	30
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS 96/24, DTS-HD HR, DTS-HD Master Audio, Dolby Digital, Dolby Dual Mono
Consumer Electronics Control (CEC)	BRAVIA Sync
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	297 mm
Width	430 mm
Height	133 mm
Weight	7100 g
