Sony STR-DH590 Help Guide

Help Guide
MULTI CHANNEL AV RECEIVER
STR-DH590
No sound or only a very low level of sound is heard, no matter which device is
selected.
Check that all connecting cables are inserted to their input/output jacks on the receiver, speakers and the devices.
Check that MASTER VOLUME on the receiver is not set to “VOL MIN”.
Press SPEAKERS repeatedly on the receiver to select a setting other than “OFF”.
Check that headphones are not connected to the receiver.
Press
to cancel the muting function.
Try pressing the input button on the remote control or turning INPUT SELECTOR on the receiver to select the input
to which you want to listen.
If the sound of a cable box or satellite box connected to the TV is not output, connect the device to an HDMI input
jack of the receiver and switch the input of the receiver to the input for the connected device (refer to the supplied
Operating Instructions).
If you want to listen to sound from the TV speaker, press AMP MENU, then set “<HDMI>” - “AUDIO.OUT” to
“TV+AMP” on the display panel. If you cannot play multi-channel audio source, set to “AMP”. However, the sound will
not be output through the TV speaker.
4-731-210-11(1) Copyright 2018 Sony Corporation
93

Sony STR-DH590 Specifications

General

Receiver type	Surround
Output impedance	6 - 16 Ω
Audio output channels	5.2 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
Digital audio optical in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Supported radio bands	FM
Preset stations quantity	30
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS 96/24, DTS-HD HR, DTS-HD Master Audio, Dolby Digital, Dolby Dual Mono
Consumer Electronics Control (CEC)	BRAVIA Sync
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	297 mm
Width	430 mm
Height	133 mm
Weight	7100 g
