FR
38 Menu INFORMATIONS
Menu INFORMATIONS
Le menu INFORMATIONS affiche les fréquences horizontale et verticale du signal
d’entrée et la durée d’utilisation de la lampe.
Ces informations sont seulement affichées. Vous ne pouvez pas modifier l’affichage.
Paramètres Fonctions Valeur de réglage
initiale
fH Affiche la fréquence horizontale du signal
d’entrée.
La valeur affichée est approximative.
fV Affiche la fréquence verticale du signal d’entrée.
La valeur affichée est approximative.
Durée de lampe Indique la durée d’utilisation effective de la
lampe.
Entrée A
fH: 48,47kHz
fV: 60,00Hz
No.23
1024x768
Durée de lampe: 0H
INFORMATIONS
Numéro de mémoire du signal d’entrée
Type de signal
Remarque
