– 98 –
10-3.Parts List
Parallel Buffer Board
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
IC1 08250011 MASKED CPU HD63B01YF-IF 1
IC2 NOT MOUNTED
IC3 08221033 PSRAM TC518128AFL-80 1
IC4 08210113 TTL IC 74LS05 (FLAT TYPE) 1
IC5-6 08210112 TTL IC 74LS00 (FLAT TYPE) 2
IC7 08210114 TTL IC 74LS112 (FLAT TYPE) 1
IC8 NOT MOUNTED
TR1 NOT MOUNTED
R1 06751021 CHIP RESISTOR 1 K-OHM 1/10W 1
R2 06781011 CHIP RESISTOR 100 OHM 1/8W 1
R3-4 06782021 CHIP RESISTOR 2 K-OHM 1/8W 2
R5-12 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 8
R13-14 06781824 CHIP RESISTOR 1.8 K-OHM 1/8W 2
R15 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 1
R16-17 NOT MOUNTED
R18-19 06751031 CHIP RESISTOR 10 K-OHM 1/10W 2
R20-22 06781812 CHIP RESISTOR 180 OHM 1/8W 3
R23-25 06751031 CHIP RESISTOR 10 K-OHM 1/10W 3
R26 06781011 CHIP RESISTOR 100 OHM 1/8W 1
R27 06751031 CHIP RESISTOR 10 K-OHM 1/10W 1
R28 06781812 CHIP RESISTOR 180 OHM 1/8W 1
RA1 06584723 RESIS. ARRAY 4.7K-OHM 1/8W 8EL 1
C1 05731041 CERA. CAPA. CHIP 0.1UF 25V 1 EXCEPT FOR HK
#2 NOT MOUNTED:FOR HK
C2 05022261 CHEM. CAPA. 22UF 16V 2
C3 05731041 CERA. CAPA. CHIP 0.1UF 25V 1
C4 05732211 CERA. CAPA. CHIP 220PF 25V 1
C5-6 05752201 CERA. CAPA. CHIP 22PF 50V 2
C7-8 NOT MOUNTED
C9 05731041 CERA. CAPA. CHIP 0.1UF 25V 1 EXCEPT FOR HK
#2 NOT MOUNTED:FOR HK
C10 05753004 CERA. CAPA. CHIP 30PF 50V 1
C11-12 NOT USED
C13-15 05731041 CERA. CAPA. CHIP 0.1UF 25V 3
C16 NOT MOUNTED
C17-20 05731041 CERA. CAPA. CHIP 0.1UF 25V 4
C21-23 05732211 CERA. CAPA. CHIP 220PF 25V 3
C24 05551045 CAPACITOR 0.1UF 50V (W) 1
CA1-3 05652212 CAPA. ARRAY 220PF 50V 8EL 3
F1 09990066 FUSE PICOII 0.5A-125V 1
XTAL1 09250027 CERA. OSCILLATOR KBR8.0MHZ 1
CN1 09100155 CONNECTOR 57L-40360-770B-D147 1
CN2 09100327 CONNECTOR AKD-30DLMDB2R 1
JW1 80924700 WIRE 26UL1007BLK060 1
JW2 80700440 WIRE 28UL1007BLK035 1
JP1 09000037 SLIDE SWITCH SSSS212 1
JP2 93930006 JUMPER WIRE STP122 1 L=14mm
JP3-5 NOT MOUNTED
JP6 09000037 SLIDE SWITCH SSSS212 1
JP7-8 93930006 JUMPER WIRE STP122 2 L=14mm
To Next Page
