– 95 –
9-3. Parts List
Serial Buffer Board
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
IC1 *2 08220102 CPU HD63A03YF 1
#2 08250011 MASKED CPU HD63B01YF-IF 1 IC6 IS NOT MOUNTED
IC2 NOT MOUNTED
IC3 08210112 TTL IC 74LS00 (FLAT TYPE) 1
IC4 08200126 IC-I/F LT1081CS 1
IC5 08200127 IC-I/F MC34051M 1
IC6 *2 08220090 EPROM 2764-200NS 1 X.**.OPB
#2 NOT MOUNTED
IC7 *1 08221011 SRAM TC5564AFL-150NS 1
#1 08221016 SRAM M5M5165FP-12 1
RA1 06584723 RESIS. ARRAY 4.7K-OHM 1/8W 8EL 1
R1-3 06781032 CHIP RESISTOR 10 K-OHM 1/8W 3
R4 06783324 CHIP RESISTOR 3.3 K-OHM 1/8W 1
R5 #1 06051036 RD RESISTOR 10 K-OHM 1/6W (W) 1
CA1-3 05652212 CAPA. ARRAY 220PF 50V 8EL 3
C1 05731042 CERA. CAPA. CHIP 0.1UF 25V 1 EXCEPT FOR HK
NOT MOUNTED :FOR HK
C2 05021066 CHEM. CAPA. 10UF 16V 1
C3-4 05732211 CERA. CAPA. CHIP 220PF 25V 2
C5-6 05752201 CERA. CAPA. CHIP 22PF 50V 2
C7-10 05034755 CHEM. CAPA. 4.7UF 25V 4
C11 05731042 CERA. CAPA. CHIP 0.1UF 25V 1
C12 NOT MOUNTED
C13 05731042 CERA. CAPA. CHIP 0.1UF 25V 1
C14 05732211 CERA. CAPA. CHIP 220PF 25V 1
C15-16 05731042 CERA. CAPA. CHIP 0.1UF 25V 2
C17 NOT MOUNTED
C18-21 05731042 CERA. CAPA. CHIP 0.1UF 25V 4
C22 05731042 CERA. CAPA. CHIP 0.1UF 25V 1 EXCEPT FOR HK
NOT MOUNTED :FOR HK
C23 NOT MOUNTED
DSW1 09090018 DIP SWITCH KSD08 1
XTAL1 09250029 CERA. OSCILLATOR CSA4.91MG 1
CN1 09100337 CONNECTOR DBLC-J25SAF-23L6 1
CN2 09100327 CONNECTOR AKD-30DLMDB2R 1
JP1 93930001 JUMPER WIRE STP123 1 L=5mm
JP2-3 09000037 SLIDE SWITCH SSSS212 2
JP4 NOT MOUNTED
JP5-6 93930001 JUMPER WIRE STP123 2 L=5mm
- *3 80086510 BOARD ID SEAL HK 1 FOR HK ONLY
To Next Page
