– 70 –

1 89131010 PRINT HEAD DP9305 1 S

2 *1 87060130 FRAME UNIT 935 1

#1 87060131 FRAME UNIT 935 1 NOTE1

3 87061110 CARRIAGE MOTOR UNIT 935 1 S

4 87067170 BAIL ROLLER SHAFT UNIT 935 1 S

5 83400650 BAIL LEVER L 935 1 S

6 *2 83400470 RELEASE LEVER 921 1 S

#2 83400471 RELEASE LEVER 921 1 S

7 83400670 SPRING HOLDER LEVER 935 2

8 *1 82401140 ADJUSTING LEVER 935 1

#1 82401141 ADJUSTING LEVER 935 1

9 82501100 HOLDER SPRING B 935 1

10 87063080 PLATEN UNIT B 935 1 S

11 81370660 TRACTOR STAY 935 1

12 87066050 TRACTOR UNIT 935 1 S

13 87067180 ROLLER HOLDER UNIT 935 4 S

14 *1 87067190 RELEASE SHAFT UNIT 935 1 INCLUDES NO.34

#1 81380520 RELEASE SHAFT 935 1 NOT INCLUDE NO.34

15 *3 87067030 TENSION LEVER UNIT 921 1

#3 87427020 TENSION LEVER UNIT 741 1

16 *1 80510860 SPRING E050-055-0358 2 S

*3 80510930 SPRING E056-060-0397 2 S

#3 80510931 SPRING E056-060-0397 2 S

17 *1 80530570 GROUND CONTACT SPRING 921 1 S

#1 80530571 GROUND CONTACT SPRING 921 1 S

18 *1 80530660 HOLDER SPRING 935 2 S

#1 80530661 HOLDER SPRING 935 2 S

19 01902612 SCREW TAT 2.6-16 PT 2 S

20 01903064 SCREW TAT 3-5 CT 1 S

21 00830604 SCREW TR 3-6 2 S

22 01903018 SCREW TR 3-6 WS/WF 1 S

23 02040404 FLANGED NUT NHW4.0-S 1 S

24 *2 02040403 TOOTHED NUT NHK4 4 S

#2 02020401 HEXAGON NUT NH4-2 4 S

25 04020015 STOP RING SE3.0 1 S

26 04020016 STOP RING SE4.0 1 S

27 04991214 MINI CORD CLAMP UAMS-05-0 1 S

28 04991230 MINI CORD CLAMP UAMS-05-SN 1 S

29 04991232 MINI CORD CLAMP UAMS-05SN-W 2 S

30 04991204 FASTENER T18S 3 S

31 *1 82900772 RIBBON HOLDER 891 1 S

*2 82900773 RIBBON HOLDER 891 1 S

#2 82902200 RIBBON HOLDER 935 1 S

32 #1 87060720 DETECTOR UNIT A ASSY 935 1

33 #1 01903073 SCREW TR 3-6 FL SPECIAL 1

34 *2 83100611 RELEASE GEAR 921 1

#2 83100612 RELEASE GEAR 921 1

35 #2 83400660 BAIL LEVER R 935 1

36 #2 87060270 CARRIAGE UNIT 935 1

37 #2 87060700 DETECTOR UNIT B ASSY 935 1

2-2. Parts List

Printer Mechanism

DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK

Note 1: Frame unit includes drawing no. 9, 13, 14, 20, 27, 32, 33, 34, 35, 36 and 37.
