TUP500 Series Product Specifications 13-4
13.3. RS232 Interface Board DIPSW
DIPSW1 Function ON OFF
DIPSW1-1
Baud Rate
(*1)
(See table below)
DIPSW1-2
DIPSW1-3 Data Length 8 bit 7 bit
DIPSW1-4 Parity Check Invalid Valid
DIPSW1-5 Parity Selection Odd Even
DIPSW1-6 Handshake DTR Mode Xon/Xoff Mode
DIPSW1-7 (Reserved) --- ---
DIPSW1-8 (Reserved) --- ---
*1) Baud Rate Settings
DIPSW1-1 DIPSW1-2 Baud Rate
ON ON 9600 bps
OFF ON 4800 bps
ON OFF 19200 bps
OFF OFF 38400 bps
