Star Micronics TUP500 series User Manual

TUP500 Series Product Specifications 3-22
3.7. Reliability Specifications
3.7.1. Thermal Mechanism Module
(1) Life: See table below.
• Mechanical Life: 20 million lines
• Thermal Head
<Printing Conditions> See the table below with average printing rate: 12.5% (Head average
resistance value change rate: Max. ±15%)
Manufacturer
Product
Name
Quality Characteristics and Use
Paper
Thickness
Head Life
(μm) Number
of Pulses
(100 Mil-
lion)
Distance
(km)
Mitsubishi Paper
Mills Limited
P220AG Normal Type 65 1.0 100
HP220A Long-storage Type 65 1.0 100
HP220AB-1 Long-storage Type 75 1.0 100
P220AGB Normal Type (For Cards and Tickets) 80 1.0 100
P220AB Normal Type (For Cards and Tickets) 85 1.0 50
PB670/
PB770
2-Color Type (Red/Black, Blue/Black) 75 0.5 50
Oji Paper Com-
pany
PD150R Normal Type 75 1.0 100
PD160R Long-storage Type 65/75 1.0 100
PD750R/
PD700R
2-Color Type (Red/Black, Blue/Black) 75 0.5 50
KSP P320RB/
P320BB
2-Color Type (Red/Black, Blue/Black) 65 0.5 50
Nippon Paper
Industries
TF50KS-
E2D
Normal Type 65 1.0 100
Notes:
1. Mechanical parts life is defined as the period at which failures from wear out is entered.
2. When two or more adjacent dots are damaged, that is considered to be the life of the head.
However, this excludes damage (scratches) caused by the adherence of foreign matter or
man-made damages.
3. When repeated printing under extremely high printing rates, the life of the thermal head
will notable decrease. Carefully consider your print format before printing.
4. The above reliability specifications are values when using the recommended thermal pa-
per. When using a different type of paper, reliability is not guaranteed.
• Auto-cutter
The table below shows cutter life when using the recommended thermal paper.
(Paper Width: 79.5 to 82.5 mm)
Paper Thickness Life
65 μm ≤ Paper Thickness ≤ 100 μm 1 Million Cuts
100 μm ≤ Paper Thickness ≤ 150 μm 300,000 Cuts
Note:
1. The contents above are values when using the recommended thermal paper.
When using a different type of paper, reliability is not guaranteed.
• Presenter Module
Number of receipt issues: 1 million receipts
