FUEL AND LUBRICATION SYSTEM 4-5
Connect the battery to the fuel pump and measure the pump
discharge amount for one minute using kerosene and measuring
cylinder, as shown in the right illustration.
Battery
++
++
+ to Brown/white
Battery
--
--
- to Black/white
$$
$$
$ Discharge amount: More than 600 ml/min
If the measurement is less than the standard value, replace the
fuel pump with a new one.
"
Do not use gasoline in this test as it is highly combus-
tible.
Fuel pump
Battery
Kerosene
Measuring
cylinder
REASSEMBLY
Carry out the assembly procedure in the reverse order of disas-
sembly.

Suzuki GSX1200 1999 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (Transistorized)
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Starting	Electric
Engine Type	4-stroke, 4-cylinder, DOHC
Fuel System	Mikuni BSR36SS carburetors
Transmission	5-speed
Rear Suspension	Link-type, coil spring, oil damped
Ground Clearance	135 mm
Seat Height	790 mm
