CHASSIS 5-9
FRONT AXLE
• Tighten the front axle 1 to the specified torque.
• Tighten the front axle pinch bolts 2 to the specified torque.
""
""
" Front axle: 100 N
.
m (10.0 kgf-m)
Front axle pinch bolt: 23 N
.
m (2.3 kgf-m)
NOTE:
Before tightening the front axle and front axle pinch bolts, move
the front fork up and down four or five times.
BRAKE CALIPERS
• Tighten the brake caliper mounting bolts to the specified torque.
""
""
" Brake caliper mounting bolt: 39 N
.
m (3.9 kgf-m)
NOTE:
* Push the pistons all the way into the brake caliper and then
remount the caliper.
* After remounting the brake calipers, pump the brake lever a few
times to check for proper brake operation.

Suzuki GSX1200 1999 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (Transistorized)
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Starting	Electric
Engine Type	4-stroke, 4-cylinder, DOHC
Fuel System	Mikuni BSR36SS carburetors
Transmission	5-speed
Rear Suspension	Link-type, coil spring, oil damped
Ground Clearance	135 mm
Seat Height	790 mm
