Sym HD300 User Manual

29
12. Specification
Model
HD 300 (LS30W1-EU)
Item
Specification
Length
2,220 mm
Width
770 mm
Height
1,230 mm
Wheel base
1,500 mm
Ground clearance
145 mm
Caster
27.5
∘
Trail
156.5 mm
Maximum load
339 kg
Curb weight
174 kg
Luggage box capacity
38 L
Seat height
800 mm
Fuel
Unleaded 92 (RON) gasoline or greater
Fuel tank capacity
10 L
Min. turning radius
2.5 m
Engine type
4T, SOHC, 4V, 1 cylinder, liquid cooled
Compression ratio
10.4:1
Displacement
278.3 cm
3
Bore
×
stroke
75 mm
×
63 mm
Max. horse power
27 PS @8000 rpm
Max. torque
2.6 kgf-m @6000 rpm
Idle speed
1,550 rpm
Starting system
Electric starter
Fuel system
EFi (fuel injection)
Ignition system
Battery and coil
Coolant capacity
1.4 L
Engine / transmission oil
SAE 10W30, API SG or greater
Lubrication system
Forced, wet sump
Engine oil capacity
1.4 L (total), 1.2 L (change)
Transmission oil capacity
180 cc (total), 160 cc (change)
Clutch / transmission
Centrifugal, CVT
Front / rear tire
110/70-16 52P, 140/70-16 65P
Front / rear tire pressure
1.8 kgf/cm
2
, 2.3 kgf/cm
2
Front / rear rim
16
×
MT3.0, 16
×
MT3.5 (aluminum alloy)
Front / rear brake disk
287 mm, 260 mm
Brake fluid
DOT 4
Spark plug
NGK CR8E
Battery
MF, YTX12-BS, 12V 10Ah
Front / rear / brake light LED
