6. Parts Location
(1)
(3)
(8)
(7)
(6)
(5)
(11)
(9)
(4)
(2)
(10)
(1). LED Headlight
(2). Passenger Footrest
(3). Coolant Level Inspection Window
(4). Side Stand Switch
(5). Side Stand
(6). Shipping Hook
(7). Fuel Lid
(8). Seat / Luggage Box
(9). Rear Carrier
(10). Tail / Brake Light
(11). Rear Turn Indicator
(12). License Plate Light
(13). Rear Shock Absorber
(14). Main Stand
(13)
(15)
(12)
(16)
(17)
(18)
(21)
(22)
(23)
(24)
(25)
(20)
(15). Rear View Mirrors
(16). Front Brake Lever
(17). Rear Brake Lever
(18). LED Position Lights
(19). Right Turn Indicator/Front
(19)
(20). Left Turn Indicator/Front
(21). Left Handlebar Switches
(22). Combination Instrument
(23). Right Handlebar Switches
(24). Throttle Grip
(25). Ignition Switch
(26). Front Compartment
HD300 (LS30W1-EU)
(26)
(14)

Sym HD300 Specifications

General

Brand	Sym
Model	HD300
Category	Scooter
Language	English
