2-53
CONTROLS
ACCESSORIES
2. Press the auxiliary hydraulic button (A) or
slide the slider switch to the left side (A).
LIFT ARM LOWER BUTTON (IF EQUIPPED)
• Do not leave the operator’s seat while
the engine is on or while the lift arm is
being raised.
• Do not lower the lift arm until you are
certain that no one is around the
machine.
IMPORTANT: The lift arm can be lowered
even when the engine is stopped or the
safety lever is in the lock position.
If the lift arm cannot be lowered during a
usual operation, press the covered button to
lower it.
Lowering the lift arm
<TL8>
<TL10/TL12>
1 Remove the rubber (1) from the top of the
button.
To Next Page
