3-9
OPERATION
OPERATING THE MACHINE
LEVER PATTERN (H) (IF EQUIPPED)
Before starting operation, be sure to check which lever pattern you are going to use.
This manual explains the operation by using the ISO pattern.
Travel Forward (Left track) Travel Forward (Right track)
Travel Reverse (Left track) Travel Reverse (Right track)
Lift Arms Raise Bucket Rollback
Lift Arms Lower Bucket Dump
Lift Arms Float
(Tilt the left control lever to the right)
Lift Arms Float
(Push the left lever to the right and
press the float button)
N Neutral N Neutral
Refer to “Selecting a lever pattern” on page 8-9.
To Next Page
