4-3
TRANSPORT
HOISTING THE MACHINE
• Know and use the correct crane signals.
• Check the hoisting equipment for
damaged or missing parts on a daily
basis and replace as necessary.
• When hoisting, use a wire rope capable
of lifting the machine mass.
• Hoist the machine in only as manner
described in the procedure below. Do
not do it in any other manner. Doing so
is dangerous as it may result in the
machine losing its balance.
• Do not hoist the machine with an
operator on it.
• When hoisting, hoist slowly so that the
machine does not tip.
• Keep everyone out of the area when
hoisting. Do not move the machine over
the heads of the persons.
IMPORTANT: This hoisting method
applies to machines with standard
specifications. This method is not
applicable for the machines with non-
standard attachments and/or optional
products, because the center of gravity
differs according to the attachments and
optional products installed. Contact your
Takeuchi service agent for details.
HOISTING THE MACHINE
Hoisting
1. Lower the bucket to the ground.
2. Raise the safety bar to the lock position.
3. Stop the engine, remove the ignition key
and get off the machine.
4. Install the wire ropes as shown on the
figure below. Install the wire ropes and
hoisting attachment without letting them
touch the machine body.
5. Hoist the machine slowly until it leaves the
ground.
6. Stop hoisting until the machine becomes
stable, and then start hoisting the machine
slowly again.
Front hook fixing position
<TL8>
<TL10/TL12>
To Next Page
