13 TR-069
TR-069 (Technical Report 069) is a method to remotely and securely manage CPE configuration
from a central Auto Configuration Server or ACS. The following figure shows a simple and
typical deployment layout. The ACS simply needs to be network accessible by the eRouter
interface.
Figure 13.1
To configure TR-069, tchTR069ClientMode should be set to enable (1) and
tchTR069ClientAcsUrl should point to the ACS server (e.g. http://myacs.acs.lab.sa).
tchTR069ClientAllowDocsisConfig must be set to enable (1) to reconfigure any TR-069
parameters including the ACS URL above.
During the initial device check-in and configuration with the ACS, the server will populate the
tchTR069ClientCrUsername and tchTR069ClientCrPassword fields. The client device identifier
can also be set as either MAC or serial number when registering to the ACS server.
13.1 User Provisioning for TR-069
The user does not configure TR-069 as it is meant for remote management by the service
operator from the auto configuration server.
13.2 SNMP Provisioning for TR-069
tchTR069ClientModeshould be set to enable (1) (TR-069 is disabled by default).
tchTR069ClientAcsUrlshould be set to the ACS IP address or FQDN.
