Security Mode:
The User can select security mode from available drop down menu for 2.4 GHz: Open, WEP 64,
WEP 128, WPA2 Personal, WPA or WPA2 Personal for 5.0 GHz: Open, WPA2 personal, WPA
or WPA2 Personal.
Recommended setting is WPA2 personal.
Encryption:
Encryption mode changes according to selection of security mode. So the user doesn’t have to
worry about correct encryption type for their security mode. For example, if security mode WPA2
Personal is selected, only AES encryption may be configured. Similarly if it is WPA or WPA2
personal, AES or TKIP encryption mode may be configured.
Network Password:
User can select whatever password they like of their choice but only when it meets the
requirement of encryption type.
1. Open: No password needed
2. WEP 64: need at least 5 ASCII characters or 10 Hex digits.
3. WEP 128: need at least 13 ASCII characters or 26 Hex digits
4. WPA2 Personal: at least 8 characters.
5. WPA or WPA2 Personal: at least 8 characters.
Key Interval:
User can make a choice what network key rotational value they want, in general it comes with
3600 sec, but user can choose between range 1- 999999.
Note: Don’t forget to hit Save tab at bottom of page after making any changes.
7.2.2 SNMP Provisioning for Wireless Security
tchRgDot11BssSecurityMode sets the security mode for the selected SSID.
tchRgDot11WepEncryptionMode sets the key length for WEP.
tchRgDot11WepPassPhrase sets the passphrase for WEP.
tchRgDot11Wep64BitKeyValue sets each 40/64-bit WEP key.
tchRgDot11Wep128BitKeyValue sets each 104/128-bit WEP key.
tchRgDot11WepDefaultKey sets the default WEP key.
tchRgDot11WpaAlgorithm sets the encryption for WPA.
tchRgDot11WpaPreSharedKey sets the passphrase or PSK for WPA.
