Broadband LED (if you are using the local router scenario)
Internet LED
Wireless LED
WPS LED
For more information about WPS, see “3.1 Connecting your wireless client via WPS” on page 26.
Colour State Description
Green Solid on Connected to the WAN device.
Off Not connected to the WAN device.
Colour State Description
Green Solid on Connected to the Internet, no activity.
Blinking Connected to the Internet, sending/receiving data.
Red Blinking Trying to connect to the Internet.
Off No Internet connection.
Colour State Description
Green Solid on The wireless interface is enabled, no wireless activity.
Blinking The wireless interface is enabled, wireless activity.
Off The wireless interface is disabled.
Both the 2.4 GHz and 5 GHz access point have a dedicated Wireless LED.
Colour State Description
Green Solid On Client successfully registered via WPS.
Orange Blinking WPS registration ongoing.
Red Blinking Error occurred.
