94
Description: Name the bandwidth control rule as you like.
IP Address Range: Type the IP address range of target hosts. Follow the example .
If you want to set one host, follow the example .
Max Upstream Speed (Kbps): Set the upstream speed as your actual bandwidth need.
Max Downstream Speed (Kbps): Set the downstream speed as your actual bandwidth need.
Status: Enable or Disable.
After you have edited the details of the bandwidth control rule, click first to save and then click to
activate the settings.
4.2.8 Routing
This section explains the following:
• Default Gateway
• Static Route
Default Gateway
Default gateway interface list can have multiple WAN interfaces served as system default gateways but only one will be
used according to the priority with the first being the highest and the last one the lowest priority if the WAN interface is
connected. Priority order can be changed by removing all and adding them back in again.
Selected Default Gateway Interfaces: Displays the selected default gateway interfaces. Select a WAN interface
and click the button to move it to the Available Routed WAN Interfaces box.
