TOHATSU MFS 4 Service Manual

4
4-19
4st 4/5/6 2011
12) Installing Carburetor
1. Reverse carburetor removing steps to install.
3
2. Attach drain screw to float bowl 3.
a
a
1
b
2
11) Adjustment of Float Height
1. Measure height a of float 1. Adjust height a of float 1 by
bending tab b if the height is out of specified range.
Float Height a :
9.0 - 10.0 mm (0.354 - 0.394 in)
Bring tab b of float 1 into light contact with top
of float valve 2.
MFS4-5-6Ech04110422.qxd 11.4.22 5:48 PM  ページ19
