Technical data
EN DE
3 Technical data
Model Cruise 10.0
Maximum input power 12 kW
Continuous input power 10 kW
6 kW when using 1x Power 48-5000
Rated voltage 48 V
Propulsive power 5.6 kW
Weight 59.8 kg (RS), 61.3 kg (RL), 62.5 kg
(RXL)
Shaft length 38.5 cm (RS), 51.2 cm (RL), 63.9 cm
(RXL)
Propeller rotational speed at max.
rotational speed
1400 rpm
Steering Accelerator lever (accessory)
Steering + - 50°
Tilt adjustment Electro-hydraulic tilt with overload
protection/grounding protection by
means of hydraulic valves
Trim mechanism Manual 4-step
Stepless forwards/reverse motion Yes
Protection class as per DIN EN 60529
Component Protection class
Motor IP67
Throttle IP67
Cable set up to main switch IP67
Main switch with connection cable IP23
ADVICE
Reaching maximum power and maximum rotational speed depends on the
Boat-Motor-Propeller combination. It may be that the maximum motor power
cannot be achieved, depending on the application.
page 67 / 113
