Torqeedo Cruise 10.0R User Manual

Operation
EN DE
6.4 Tilt switch
CAUTION!
Danger of crushing if motor tilts.
Slight or moderately severe physical injuries may result.
■
When tilting the motor using the tilt switch, ensure that no-one is present in
the vicinity of the motor.
■
Do not reach into the mechanical parts when tilting the motor.
2
1
Fig. 54: Tilt switch
1
Tilting upwards
2
Tilting downwards
The motor can be tilted upwards or downwards using the tilt switch.
Tilting upwards
1. Press on the upper half of the tilt switch (1).
The motor is tilted upwards hydraulically.
65°
Fig. 55: Motor is tilted fully upwards
page 91 / 113
