6 1600XPi Series UPS Installation and Operation Manual – 60616-014
3 Important Safety Instructions
This manual contains important instructions that should be followed during the installation and maintenance of the UPS and
its batteries.
Hardwired UPS units are not equipped with an over-current protection device nor an output disconnect for the AC output.
Circuit breakers should be provided by the user between the UPS Input and utility power, and the UPS output and the load
input. These devices should be rated as follows:
240VAC
RATING
3.6 kVA 5.2/6 kVA 8 kVA 10 kVA 14 kVA 18 kVA 22 kVA
Input
Breaker
30 A 50 A 60 A 70 A 100 A 100 A 125 A
Output
Breaker
20 A 35 A 45 A 60 A 80 A 100 A 125 A
* Ratings are for an 80% rated device.
The nominal battery voltages for these models are as follows:
BATTERY
VOLTAGE
3.6 kVA 5.2/6 kVA 8 kVA 10 kVA 14 kVA 18 kVA 22 kVA
144 Vdc 216 Vdc 288 Vdc 288 Vdc 288 Vdc 288 Vdc 288 Vdc
Servicing of the batteries should only be performed by a qualied factory authorized representative who is knowledgeable
about batteries and the required precautions. Keep unauthorized personnel away from batteries. To arrange for battery
replacement, contact Toshiba Customer Support Center.
1. Turn o󰀨, lockout, and tagout all equipment before connecting the power wiring to the equipment or when performing
maintenance.
2. The maximum ambient operating temperature is 104 °F (40 °C).
3. Access panels should only be removed by authorized Toshiba eld Service personnel.
4. UPS servicing should be performed by qualied Toshiba representatives only.
5. Battery servicing should be performed by qualied Toshiba representatives only.
6. Contact your Toshiba authorized service center for battery replacement.
