58 1600XPi Series UPS Installation and Operation Manual – 60616-014
Display Recorded Meaning Action
EXTBC2 N 1. BC2 Battery String 1, 2, or 3
Loose HCT Connection
2. BC2 Over Voltage Fault
3. BC2 Over Current Fault
• Call Toshiba for Service.
• Call Toshiba for Service
• Call Toshiba for Service
FSOPEN Y Fuse Open. Replace fuse.
INVOLNR Y Inverter Overload (Not Reset-
table) – Output overload condition
occurred.
Reduce equipment load to 100% or less and
manually restart the UPS.
INVOLR Y Inverter Overload (Resettable) –
Output overload condition oc-
curred.
Reduce equipment load to 100% or less, the UPS
will retransfer.
OOC Y Output Overcurrent – UPS is over-
loaded.
Shut down excess equipment to reduce load.
VOOV Y Output Overvoltage – Output over-
voltage condition occurred.
UPS is possibly faulty. Check the UPS operation
conditions at time of fault. Not advisable to restart
the UPS. Call Toshiba for service.
VOUV Y Output Undervoltage – Output
undervoltage condition occurred.
UPS is possibly faulty. Check the UPS operation
conditions at time of fault. Not advisable to restart
the UPS. Call Toshiba for service.
23.4 System Warning Messages
Warning messages are generated when a noncritical abnormal operating condition occurs. The following tables shows
possible messages and their meaning.
When a Warning condition exists, the amber LED on the UPS display panel will ash for the duration of the Warning con-
dition.
All warnings will clear after the appropriate action has been taken.
Display Recorded Meaning Action
AOH Y Ambient Overheat – The unit is
overheated (warning is given when
the internal temperature reaches
and exceeds 50° C ambient).
Check to see if the ambient temperature is greater
than 104 °F (40 °C) If so, turn on air conditioning
and check the ventilation fan at the back of the
unit for operation or obstructions. Otherwise, shut
down the unit and call Toshiba for service.
ASYN N Asynchronous mode – Input and
output frequency are di󰀨erent.
Bypass is disabled.
No Action Needed.
BDEPL N Battery Depleted – Battery not
within specications.
Call Toshiba for service.
BLFE Y Battery Lifetime End – Batteries at
end of life.
Batteries at end of scheduled ve year service
life. Contact Toshiba authorized representative for
service. (Operating at temperatures in excess of
77 °F (25 °C) may decrease battery’s scheduled
service life.)
BLFN Y Battery Lifetime Near End – Bat-
teries are nearing the end of their
expected lifetime.
Battery has 6 months or less of scheduled service
life.
