411600XPi Series UPS Installation and Operation Manual – 60616-014
16.2 Settings Parameters
Appendix B lists all parameters that can be accessed under the MONITOR tab of the touchscreen display.
Depending on the access level, parameters may be either read and written to (e.g. ), read only, or hidden from view ex-
cept at a higher access level.
Parameters are displayed at higher access levels and not a lower access levels in order to reduce operator information
overload.
The security levels are, from lowest to highest level:
Access Level Sec. Abbreviation
User USR
Administrator ADM
Dealer* DLR
Service/QC* SVC
Factory* ENG
* DLR, SVC, and ENG are restricted to factory and factory authorized service providers only.
The table headings are:
• Cmd ID - Command ID number. A three digit number between 000 and 999. Not all numbers have an associated
parameter.
• Description on LCD - Display text, often abbreviated.
• Brief Description - Brief description of the function of the parameter.
• Location Map - Tab/Blk - Gives the menu location for the parameter by Tab and Block.
The tabs are Main, Monitor, Settings, Records.
E.g. Cmd 501 (Battery Voltage can be viewed under the Monitor tab, in the BATT block)
UPS Status is displayed in the display header Status eld.
UPS Faults and Warnings are shown in the display footer, at the bottom of the display.
• Example - Shows an example of the parameter displayed on the touchscreen.
• Rqd Security Level to Change/By - The required security level to change a parameters value or setting: User, Ad-
ministrator, Distributor.
