291600XPi Series UPS Installation and Operation Manual – 60616-014
13 Touchscreen Menu Tree
13.1 Front Panel Layout
The diagram below shows the menu tree for the touchscreen display. The four folder tabs and their associated sub-menu
choices are shown on the left, and a description of the displays /choices are detailed on the right.
MAIN – Displays the starting screen. It
has a RUN and STOP key that place the
UPS in In-Line or Bypass mode respec-
tively.
MONITOR – Graphically displays the
current status of the UPS (OnLine, Back-
up, Bypass, Shutdown) in an interactive
power ow block diagram. Selecting one
of the blocks provides additional detailed
data of the Input (IN), Output (OUT), By-
pass (BYP), Battery (BAT), and DC Bus
(DC), Control & Conguration (C&C),
and Display & External (D&E) devices.
SETTINGS – Allows monitoring and/or
modication of UPS parameters. Pa-
rameters that can be viewed or modied
vary depending on the security level of
the login password entered using key-
pad.
Records – Displays the most recent 32
Test, Backup, Faults, Warning, Opera-
tion, and System change records.
System records are only available at the
distributor and depot security levels.
In any record set, if more than 32 inci-
dences have occurred, only the most
recent 32 record are retained in each
report.
Tab: Main ID / RUN-STOP
Tab: Settings
Settings Menu
Disp/Reye
Ctrl/Cfg
DC Bus
Output
ID Input
History
Batt
Bypass
Tab: Records
Records Menu
Warnings
Backup
SystemOperation
Faults
Test
Tab: Monitor
Monitor Menu
BYP
OUT
DC
IN BAT
D&R
C&C
To Next Page
