159
Exploring Your Computer’s Features
Using Slim SelectBay® modules
5.375 x 8.375 ver 2.3
❖ Secondary hard disk drive (HDD)
HINT: Items from this list that did not come with your computer
can be purchased separately. See the accessories information
packaged with your system or visit accessories.toshiba.com.
Removing a module from the Slim SelectBay
®
Use caution when lifting or turning your computer. Failure to
do so may result in damage to components, such as cables,
attached to your computer, or to the computer itself.
1 Do one of the following:
❖ Turn off the computer.
❖ Leave the computer on and hot swap the module. First,
stop the module by clicking the Safely Remove
Hardware icon on the System tray. After the module is
stopped, it is safe to remove it.
2 Turn the computer upside down and slide the Slim
SelectBay release latch toward the back of the computer.
Sample unlatching the Slim SelectBay module
To Next Page
