TOSHIBA
Function Function Adjustment Factory Error Ref.
No. Name Display Range Unit Set Message Page
8 Multi-function input 0 : SS2, SS3 0 8-24
1 : JOG, SS3
2 : SS2, AD2
3 : JOG, AD2
7th speed LL to UL setting value Hz 0 8-23
2nd speed LL to UL setting value Hz 0 8-23
5.5 Multiple Preset Speeds
· Up to 7 different preset speeds can be executed without any external potentiometers.
· These 7 preset speed frequency values can be accessed either through the terminal
input (Remote Control) or through the keypad (Panel Control). Also note that an
8th speed can be executed when the inverter has an operating frequency set
through the terminal input reference signal.
· The preset frequencies are set to particular frequencies via Function #6 - parameters
SR1 thru SR7.
Output
frequency
1st speed (Sr1)
7th speed (Sr7)
5th speed (Sr5)
3rd speed (Sr3)
Time
2nd speed (Sr2)
6th speed (Sr6)
4th speed (Sr4)
5 - 6
EXAMPLE
1st speed LL to UL setting value Hz 0 8-23
3rd speed LL to UL setting value Hz 0 8-23
6 4th speed LL to UL setting value Hz 0 8-23
5th speed LL to UL setting value Hz 0 8-23
6th speed LL to UL setting value Hz 0 8-23
Preset Functions Required To Run the Preset Speeds
SS3-CC
OFF
OFF
OFF
OFF
ON
ON
ON
ON
SS2-CC
OFF
OFF
ON
ON
OFF
OFF
ON
ON
SS1-CC
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Operating Frequency Selection
Operating Frequency set via PP, RR, IV terminal
1st Operating Speed Frequency
2nd Operating Speed Frequency
3rd Operating Speed Frequency
4th Operating Speed Frequency
5th Operating Speed Frequency
6th Operating Speed Frequency
7th Operating Speed Frequency
F/R-CC
ON
ST-CC
ON
ST
R
F
SS1
CC
SS3
SS2
