TOSHIBA
DC injection time 0.0 to 5 sec 0 8-27
8.3.3 Jog
The jog frequency is immediately output regardless of the predetermined
acceleration time. The jog frequency (JOG) and the type of jog stop pattern
(J.StP) must be pre-selected.
8 - 7
The following table identifies the STOP pattern and the next table illustrates a
JOG RUN in which the parameters "JOG" and "J.Stp" equal 5Hz and 1,
respectively.
6 Jog drive frequency 0 to 20 Hz 5 8-23
Jog stop control 0: Deceleration stop
1: Coast stop 0 8-23
2: DC injection stop
Function Function Adjustment Factory Error Ref.
No. Name Display Range Unit Set Message Page
DC injection starting 0.0 to 10 Hz 0 8-27
2ND frequency
1 DC injection voltage 0 to 20 % 0 8-27
Function Parameters
0 Motor will decelerate to a stop at the rate of DEC1, or DEC2, (dependent upon SEL2).
1 Motor will coast to a stop.
2 Motor will have DC injection applied based upon the DC injection parameters located
in the 2nd Function #1.
Key Action Display
The inverter must be placed in the monitor mode and stopped before
activating the jog feature.
Engages the jog feature.
Sets a forward run jog.
Sets a reverse run jog.
When held down the inverter will run at the preset jog speed.
When released the motor coasts to a stop (J.StP=1).
Disables the jog feature. The inverter returns to the monitor mode.
MON
2ND 0
RUN
RUN
CLR
STOP
or
Pattern
Jogging Stop Pattern
Activating the JOG Feature
