9-5
■ Specifications
■ Others
1. Fork & Backrest
The fork and backrest are the same as those of the standard vehicles. Series options can be used as
they are.
2. A4 Piping
The E9 attachment includes the A4 piping as shown in the table below.
3. Control Lever Layout
The control lever layout remains unchanged. The operating directions are also the same.
7FBEF15 to 18 STD: Standard ●: Available as option
Fork bar width mm (in) 920 (36.2)
Catalog No. 55F-SS-A890
Assembly weight kg (lb) 50.3 (111)
Effective thickness mm (in) 59.0 (2.32)
Max. sideshift mm (in) 200 (7.87)
Series STD
7FBEF20 STD: Standard ●: Available as option
Fork bar width mm (in) 1020 (40.2) 1170 (46.1) 1470 (57.9)
Catalog No. 55F-SS-A891 55F-SS-A930 55F-SS-A932
Assembly weight kg (lb) 53.5 (2.11) 59.0 (2.32) 88.3 (3.48)
Effective thickness mm (in) 59.0 (2.32) ←←
Max. sideshift mm (in) 200 (7.87) ←←
Series STD ●●
E9-code A4-type
E911 A410
E911A A430
E911B A450
2
3
9
