9-6
Integral sideshifter
■ General
• The sideshifter integrated with the lift bracket is provided.
• The basic structure remains unchanged from that for previous models.
• It can be installed on V, FSV and FV (1-t series) masts.
• The allowable load and load center are the same as those on standard vehicles.
Rear view of integral sideshifter
■ Specifications
7FBEF15 to 18 STD: Standard
Fork bar width mm (in) 920 (36.2)
Max. sideshift mm (in) 200 (7.87)
Series STD
7FBEF20 STD: Standard ●: Available as option
Fork bar width mm (in) 1020 (40.2) 1170 (46.1) 1470 (57.9)
Max. sideshift mm (in) 200 (7.87) ←←
Series STD ●●
Stroke Stroke
Fork bar width
