9-23
BATTERY ROLL-OUT SPECIFICATION
■ General
• Provided for all models.
■ Structure
Battery roll-out vehicles have different frame structure from the standard vehicle as they replace battery
from the RH side.
The batteries are the same as those for standard vehicles.
The following indicate main structure:
Part A
Metal roller guide and rollers can be installed under the battery. They enable battery replacement with
ease without using the tool.
Battery stopper
A
Roller guide (steel) Rollers
FR
RH
