5-27
4
I/O MONITOR3
(material handling
system and mast
control)
I/O 3-1
L: −.−− −.−− 1− Lift switch: 0 (OFF), 1 (ON)
*1
L:0.90 3.50 10
Lift lever angle 1 sensor voltage: V
Lift lever angle 2 sensor voltage: V
Lift raise switch: 0 (OFF), 1 (ON)
Lift lower switch: 0 (OFF), 1 (ON)
I/O 3-2
L (SOL):−.−− Unused
*1
L (SOL):0.35
Lift proportional valve current: A
I/O 3-3
T:−.−− −.−− 10
Forward tilt switch: 0 (OFF), 1 (ON)
Backward tilt switch: 0 (OFF), 1 (ON)
*1
T:0.90 3.50 10
Tilt lever angle 1 sensor voltage: V
Tilt lever angle 2 sensor voltage: V
Forward tilt switch: 0 (OFF), 1 (ON)
Backward tilt switch: 0 (OFF), 1 (ON)
I/O 3-4
T (SOL):−.−− Unused
*1
T (SOL):0.35
Tilt proportional valve current: A
I/O 3-5
A1: −.−− −.−− 1− Attachment 1 switch: 0 (OFF), 1 (ON)
*2
A1:0.90 3.50 01
Attachment 1 lever angle 1 sensor voltage: V
Attachment 1 lever angle 2 sensor voltage: V
Attachment 1 raise switch: 0 (OFF), 1 (ON)
Attachment 1 lower switch: 0 (OFF), 1 (ON)
I/O 3-6
A1 (SOL):−.−− Unused
*2
A1 (SOL):0.35
Attachment 1 proportional valve current: A
I/O 3-7
A2:−.−− −.−− −− Unused
*3
A2:0.90 3.50 01
Attachment 2 lever angle 1 sensor voltage: V
Attachment 2 lever angle 2 sensor voltage: V
Attachment 2 raise switch: 0 (OFF), 1 (ON)
Attachment 2 lower switch: 0 (OFF), 1 (ON)
I/O 3-8
A2 (SOL):−.−− Unused
*3
A2 (SOL):0.35
Attachment 2 proportional valve current: A
I/O 3-9 SWTK:0 Tilt knob switch: 0 (OFF), 1 (ON)
I/O 3-10
SSP:2000
[2000]
Pump motor rpm: rpm
[Main controller instruction rpm: rpm]
I/O 3-11 MH:10− Lifting height switch: 0 (OFF), 1 (ON)
I/O 3-12 POTT:2.50 Tilt angle sensor voltage: V
I/O 3-13 SPL:0.84 (1.7) Load sensor voltage: V (MPa display)
ANALYZER MENU
screen
Display
Meaning
1st column 2nd column
