Configuration Procedure:
Step Operation Description
1 Configure IP-Range Required. Configure IP-Range to be filtered on
Multicast→Multicast Filter→IP-Range page.
2 Configure multicast filter
rules for ports
Optional. Configure multicast filter rules for ports on
Multicast→Multicast Filter→Port Filter page.
8.4 Packet Statistics
On this page you can view the multicast data traffic on each port of the switch, which facilitates you
to monitor the IGMP messages in the network.
Choose the menu Multicast→Packet Statistics to load the following page.
Figure 8-12 Packet Statistics
The following entries are displayed on this screen:
¾ Auto Refresh
Auto Refresh: Select Enable/Disable auto refresh feature.
Refresh Period: Enter the time from 3 to 300 in seconds to specify the auto refresh
period.
113
