Step Operation Description
2 Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config
page, click the Create button to create a VLAN. Enter the
VLAN ID and the description for the VLAN. Meanwhile,
specify its member ports.
3 Create Protocol Template. Required. On the VLAN→Protocol VLAN→Protocol
Template page, create the Protocol Template before
configuring Protocol VLAN.
4 Create Protocol VLAN. Required. On the VLAN→Protocol VLAN→Protocol
VLAN page, select the protocol type and enter the VLAN ID
to create a Protocol VLAN.
5 Modify/View VLAN. Optional. On the VLAN→Protocol VLAN→Protocol VLAN
page, click the Edit button to modify/view the information of
the corresponding VLAN.
6 Delete VLAN. Optional. On the VLAN→Protocol VLAN→Protocol VLAN
page, select the desired entry to delete the corresponding
VLAN by clicking the Delete button.
6.4 Application Example for 802.1Q VLAN
¾ Network Requirements
z Switch A is connecting to PC A and Server B;
z Switch B is connecting to PC B and Server A;
z PC A and Server A is in the same VLAN;
z PC B and Server B is in the same VLAN;
z PCs in the two VLANs cannot communicate with each other.
¾ Network Diagram
68
