TP-Link tl-wr845n User Manual

TL-WR845N
300Mbps Wireless N Router
 One 10/100M Auto-Negotiation RJ45 WAN port, four 10/100M Auto-Negotiation RJ45 LAN
ports, supporting Auto MDI/MDIX.
 Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication, TKIP/AES encryption security.
 Shares data and Internet access for users, supporting Dynamic IP/Static IP/PPPoE Internet
access.
 Supports Virtual Server, Special Application and DMZ host.
 Supports UPnP, Dynamic DNS, Static Routing.
 Provides Automatic-connection and Scheduled Connection on certain time to the Internet.
 Built-in NAT and DHCP server supporting static IP address distributing.
 Built-in firewall supporting IP address filtering, Domain Name filtering, and MAC address
filtering.
 Connects Internet on demand and disconnects from the Internet when idle for PPPoE.
 Provides 64/128/152-bit WEP encryption security and wireless LAN ACL (Access Control
List).
 Supports Flow Statistics.
 Supports firmware upgrade and Web management.
 Supports Guest Network.
 Supports IPv6 Internet Connection.
 Supports Tether App to manage the router on smart devices.
1.3 Panel Layout
1.3.1 The Front Panel
-3-

TP-Link tl-wr845n Specifications

General

DSL WAN	No
Ethernet WAN	Yes
VPN support	PPTP, L2TP, IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Memory card slot(s)	-
Ethernet LAN (RJ-45) ports	5
Product type	Tabletop router
Product color	White
Antennas quantity	3
Antenna gain level (max)	5 dBi
Output current	0.6 A
Output voltage	9 V
Power source type	DC
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, RoHS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	144 mm
Width	230 mm
Height	35 mm
