TP-Link tl-wr845n User Manual

TL-WR845N
300Mbps Wireless N Router
 Address Lease Time - The Address Lease Time is the amount of time a network user will
be allowed connection to the router with their current dynamic IP Address. Enter the amount
of time in minutes and the user will be "leased" this dynamic IP Address. After the time is up,
the user will be automatically assigned a new dynamic IP address. The range of the time is 1
~ 2880 minutes. The default value is 120 minutes.
 Default Gateway - (Optional.) Suggest to input the IP address of the LAN port of the router,
default value is 192.168.0.1
 Default Domain - (Optional.) Input the domain name of your network.
 Primary DNS - (Optional.) Input the DNS IP address provided by your ISP. Or consult your
ISP.
 Secondary DNS - (Optional.) Input the IP address of another DNS server if your ISP
provides two DNS servers.

Note:
To use the DHCP server function of the router, you must configure all computers on the LAN as
"Obtain an IP Address automatically" mode.
4.8.2 DHCP Clients List
Choose menu “DHCP > DHCP Clients List”, you can view the information about the clients
attached to the router in the next screen.
 ID - The index of the DHCP Client
 Client Name - The name of the DHCP client
 MAC Address - The MAC address of the DHCP client
 Assigned IP - The IP address that the router has allocated to the DHCP client.
 Lease Time - The time of the DHCP client leased. After the dynamic IP address has expired,
a new dynamic IP address will be automatically assigned to the user.
You cannot change any of the values on this page. To update this page and show the current
attached devices, click the Refresh button.
4.8.3 Address Reservation
Choose menu “DHCP > Address Reservation”, you can view and add a reserved addresses for
clients via the next screen.When you specify a reserved IP address for a PC on the LAN, that PC
-45-

TP-Link tl-wr845n Specifications

General

DSL WAN	No
Ethernet WAN	Yes
VPN support	PPTP, L2TP, IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Memory card slot(s)	-
Ethernet LAN (RJ-45) ports	5
Product type	Tabletop router
Product color	White
Antennas quantity	3
Antenna gain level (max)	5 dBi
Output current	0.6 A
Output voltage	9 V
Power source type	DC
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, RoHS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	144 mm
Width	230 mm
Height	35 mm
