Trane RTHD series User Manual

Installation Mechanical
60 RTHD-SVX02H-EN
Table 14. Pressure Relief Valve Data
Valve Location Discharge
Setpoint
(psi)
Number
of Valves
Rated Capacity
per Relief Valve
(lba/min.)
Field Connection
Pipe Size (in NPT)
Factory
Shell Side
Connection(in)
Evap - B1 200 2 48.0 1 1-5/16-12
Evap - B2 200 2 48.0 1 1-5/16-12
Evap - C1 200 2 48.0 1 1-5/16-12
Evap - C2 200 2 48.0 1 1-5/16-12
Evap - D1 200 2 48.0 1 1-5/16-12
Evap - D2 200 2 48.0 1 1-5/16-12
Evap - D3 200 2 48.0 1 1-5/16-12
Evap - D4 200 2 48.0 1 1-5/16-12
Evap - D5 200 2 48.0 1 1-5/16-12
Evap - D6 200 2 48.0 1 1-5/16-12
Evap - E1 200 2 48.0 1 1-5/16-12
Evap - F1 200 2 48.0 1 1-5/16-12
Evap - F2 200 2 48.0 1 1-5/16-12
Evap - G1 200 2 48.0 1 1-5/16-12
Evap - G2 200 2 48.0 1 1-5/16-12
Evap - G3 200 2 48.0 1 1-5/16-12
Cond - B1 200 2 48.0 1 1-5/16-12
Cond - B2 200 2 48.0 1 1-5/16-12
Cond - D1 200 2 48.0 1 1-5/16-12
Cond - D2 200 2 48.0 1 1-5/16-12
Cond - E1 200 2 48.0 1 1-5/16-12
Cond - E2 200 2 48.0 1 1-5/16-12
Cond - E3 200 2 48.0 1 1-5/16-12
Cond - E4 200 2 48.0 1 1-5/16-12
Cond - E4 200 2 48.0 1 1-5/16-12
Cond - E5 200 2 48.0 1 1-5/16-12
Cond - F1 200 2 48.0 1 1-5/16-12
Cond - F2 200 2 48.0 1 1-5/16-12
Cond - F3 200 2 48.0 1 1-5/16-12
Cond - G1 200 2 48.0 1 1-5/16-12
Cond - G1 200 2 48.0 1 1-5/16-12
Cond - G3 200 2 48.0 1 1-5/16-12
Cond - H1 200 2 48.0 1 1-5/16-12
Cond - H2 200 2 48.0 1 1-5/16-12
Cond - J1 200 2 48.0 1 1-5/16-12
Cond - J2 200 2 48.0 1 1-5/16-12
Cond - J3 200 2 48.0 1 1-5/16-12
Cond - K1 200 2 48.0 1 1-5/16-12
Cond - L1 200 2 48.0 1 1-5/16-12
Cond - L2 200 2 48.0 1 1-5/16-12
Cond - M1 200 2 48.0 1 1-5/16-12
Cond - M2 200 2 48.0 1 1-5/16-12
Cond - M3 200 2 48.0 1 1-5/16-12
Cond - N1 200 2 48.0 1 1-5/16-12
Comp - B1/B2* 200 2 78.8 1-1/4 1-5/8-12
Comp - C1/C2* 200 3 78.8 1-1/4 1-5/8-12
Comp - D1/D2/D3* 200 3 78.8 1-1/4 1-5/8-12
Comp -E3* 200 3 78.8 1-1/4 1-5/8-12
* Only used with isolation valve option
