Waterbox Removal and Installation
64 RTHD-SVX02H-EN
D
WARNING
Safety Hoist Ring Modication!
The modication shown in Figure 31 must be complete
prior to using the hoist ring to lift the waterbox. Failure
to make these modication could result in death or
serious injuries.
The length of the standard hoist ring bolt must be
shortened (modified) prior to use for lifting waterboxes.
Shorting of the bolt as instructed will help insure the
base of the hoist right is flat against the waterbox when
properly seated. If bases of hoist is not properly seated
against waterbox side loading on the bolt may occur
which could lead to bolt failure.
Questions
Contact the Product Technical Service department in
Taicang, China with questions regarding this Service Bul-
letin. They can be reached at baojjw@trane.com.
