Triumph Speed Triple R User Manual

Maintenance and Adjustment
112
The standard suspension settings
provide a comfortable ride and good
handling characteristics for general, solo
riding. The chart shows suggested
settings for the front and rear
suspension.
Front Suspension Adjustment
Spring Pre-Load Adjustment
1. Speed Triple S spring pre-load
adjuster
1. Speed Triple R spring pre-load
adjuster
The spring pre-load adjusters are
located at the top of each fork.
Warning
Make sure that the correct balance
between front and rear suspension is
maintained. Suspension imbalance
could significantly change handling
characteristics leading to loss of
control and an accident. Refer to the
chart on page 111 for further
information or consult your dealer.
Warning
Make sure that the adjusters are set
to the same setting on both forks.
Settings which vary from left to right
could significantly change handling
characteristics leading to loss of
control and an accident.
1
cgfj_1
1
chcy

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
