Maintenance and Adjustment
97
Fuel Tank
Note:
• The fuel tank may be raised without
being removed completely, for
access to the battery and the
coolant expansion tank for filling up.
Raising
Remove the seats (see page 62) and
remove the fuel tank support from its
location on the rider’s seat base.
Store the seat as described on page 63.
1. Rider’s seat
2. Fuel tank support
Release the three fixings and remove
the front panel from the fuel tank.
1. Front panel
2. Fixings
Remove the front fixings for the fuel
tank.
1. Fixings
2. Fuel tank
