Warning Labels
W
arning Label Locations (continued)
Caution
All warning labels and decals, with the exce
ption of the Running-in label, ar
e fitted
to the motorcycle
using a strong adhesive. I
n some cases, labels are in
stalled prior
to an application of paint lacquer. Therefore, any attempt to remo
ve the warning
labels will cause dam
age to the paintwork or bodywo
rk.
Helmet
(page
7
)
Unleaded Fu
el
(page
58
)
Daily Safety
Checks (page
65
)
Coolant
(page
94
)
Engine Oil
(page
90
)
12
