Triumph Thunderbird User Manual

22
General Information
Instruments
Speedometer
The speedometer indicates the road speed of
the motorcycle.
Tachometer
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). On the
right side of the tachometer face is the 'red
zone'. Engine rpm (r/min) in the red zone is
above the maximum recommended engine
speed and is also above the range for best
performance.
Odometer/Trip Meter/Clock
1. Odometer/Trip meter display
The odometer shows the total distance that
the motorcycle has travelled.
There are two trip meters. Either trip meter
shows the distance that the motorcycle has
travelled since the meter on display was last
reset to zero.
To switch between the trip meter, clock and
range to empty display modes, press and
release the scroll button (see below), located
on the right hand handlebar switch housing,
until the desired display is visible.
1. Scroll button
The display will scroll through in the order:
•Odometer;
• Trip meter 1;
• Trip meter 2;
•Clock;
•Range to empty.
Caution
Never allow engine rpm to enter the 'red
zone' as severe engine damage may result.
TRIP
1
Warning
Do not attempt to switch between
odometer and trip meter display modes or
reset the trip meter with the motorcycle in
motion as this may lead to loss of
motorcycle control and an accident.
cfcc
1

Triumph Thunderbird Specifications

General

Manufacturer	Triumph
Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Tubular steel, twin spine
Front Tyre	120/70 R19
Rear Tyre	200/50 R17
Seat Height	700 mm
Fuel System	Fuel injection
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm floating discs
Rear Brakes	Brembo 2-piston caliper
Fuel Tank Capacity	22 L
Power	97 hp (72 kW) @ 5900 rpm
