Triumph Thunderbird User Manual

42
How to Ride the Motorcycle
1. Ignition switch
2. Engine stop switch
3. Starter button
4. Neutral light
To Stop the Engine
Close the throttle completely.
Select neutral.
Turn the ignition switch off.
Select first gear.
Support the motorcycle on a firm, level
surface with the side stand (see page 48).
Lock the steering (see page 28).
To Start the Engine
Check that the engine stop switch is in the
RUN position.
Ensure the transmission is in neutral.
Turn the ignition switch on.
Note:
• When the ignition is switched on,
the instrument warning lights will
illuminate and will then go off
(except those which normally
remain on until the engine starts -
see 'Warning Lights' on page 24).
cfcv
P
TRIP
530;
1
2
3
4
Caution
The engine should normally be stopped by
turning the ignition switch to the OFF
position. The engine stop switch is for
emergency use only. Do not leave the
ignition switched on with the engine
stopped. Electrical damage may result.

Triumph Thunderbird Specifications

General

Manufacturer	Triumph
Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Tubular steel, twin spine
Front Tyre	120/70 R19
Rear Tyre	200/50 R17
Seat Height	700 mm
Fuel System	Fuel injection
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm floating discs
Rear Brakes	Brembo 2-piston caliper
Fuel Tank Capacity	22 L
Power	97 hp (72 kW) @ 5900 rpm
