Triumph Thunderbird User Manual

34
General Information
Side Stand
1. S i d e s t a n d
The motorcycle is equipped with a side stand
on which the motorcycle can be parked.
Note:
• When using the side stand, always
turn the handlebars fully to the left
and leave the motorcycle in first
gear.
Whenever the side stand is used, before
riding, always ensure that the stand is fully up
after first sitting on the motorcycle.
For instructions on safe parking, refer to the
'How to Ride the Motorcycle' section.
Side Panels
1. Side panel (right hand shown)
2. Grommets
Side panel removal is required to access the
fusebox and the tool kit Allen key.
To remove either side panel, grasp the panel
firmly in both hands pull the panel away from
the motorcycle until it clears the three
retaining grommets (leaving the grommets in
place).
To refit, position the three locating dowels to
the grommets, then press firmly to secure the
panel.
Ensure the panel is correctly located over the
upper and lower locating dowels.
Finally, grasp the panel and ensure that it is
fully retained.
Warning
The motorcycle is fitted with an interlock
system to prevent it from being ridden
with the side stand in the down position.
Never attempt to ride with the side stand
down or interfere with the interlock
mechanism as this will cause a dangerous
riding condition leading to loss of
motorcycle control and an accident.
1
cfbo
1
2
2
cfhl

Triumph Thunderbird Specifications

General

Manufacturer	Triumph
Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Tubular steel, twin spine
Front Tyre	120/70 R19
Rear Tyre	200/50 R17
Seat Height	700 mm
Fuel System	Fuel injection
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm floating discs
Rear Brakes	Brembo 2-piston caliper
Fuel Tank Capacity	22 L
Power	97 hp (72 kW) @ 5900 rpm
